| SPECIFICATIONS: | |
|---|---|
| Neck type: | GRG / Maple neck |
| Top/Back/Body: | Poplar (Okoume for WNF) body |
| Fretboard: | Bound Treated New Zealand PineSharktooth inlay |
| Fret: | Jumbo frets |
| Bridge: | Ibanez F106 bridge |
| String Space: | 10.5mm |
| Neck Pickup: | IBZ-6 (H) neck pickupPassive/Ceramic |
| Bridge Pickup: | IBZ-6 (H) bridge pickupPassive/Ceramic |
| hardware color: | Black |
| Neck Dimensions | |
|---|---|
| Scale : | 648mm/25.5" |
| a : Width | 43mm at NUT |
| b : Width | 58mm at 24F |
| c : Thickness | 19.5mm at 1F |
| d : Thickness | 21.5mm at 12F |
| Radius : | 400mmR |
| Guitar Neck Diagram | |
|---|---|
| a: Width of the neck at the nut | |
| b: Width of the neck at the first fret | |
| c: Thickness of the neck at the first fret | |
| d: Thickness of the neck at the twelfth fret | |
| Radius: Radius of the fingerboard | |
SWITCHING SYSTEM
When the pickup selector switch is in neck position, the neck pickup is selected. When the switch is in between neck and center position, bridge side of the neck pickup is selected. When the switch is in center position, both neck and bridge pickup s are selected. When the switch is in between center and bridge position, the bridge side of the neck pickup and the bridge side of the bridge pickup are selected. When the switch is in bridge position, bridge pickup is selected.
CONTROLS
With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.
